PR Express Panel PWM SunSaver 20L-12V
Assembled control panel for stand-alone uses or in our express shipped PRE systems. If in stock ships 1-3 days, backordered ships 2-3 weeks.
From: $397.17
Features
- 20 amp, 12 volt nominal charge controller
- Charge controller features Low Voltage Disconnect (LVD)
- Charge controller rated for 25% overload for 5 min
- Includes low frequency Telecom Mode
- Automatic recovery without fuses
Product Data
PR Express Panel PWM SunSaver 20L-12V
SunWize PR Express Panel PWM 230036 is a prewired aluminum control panel for our Power Ready Express systems. It has all of the necessary switchgear to hook up a charge/load controller to a solar array, battery bank, and load. SunWize Charge controllers have ratings between 6A and 40A are available in standard power ready express control panel configurations. The PWM versions can use the power from the solar array more efficiently than the standard PR Express control panels and have additional features.
The control panel consists of an aluminum backplate; a charge controller; two load terminals; and breakers for the array, battery, and load. All breakers are sized to match the rating of the charge controller.
Save time & money by purchasing the complete Power Ready Express Systems!
